V-22 Osprey Nacelle Maintenance Fixture

The nacelle houses the tiltrotor's engine and gearbox systems, making it one of the most complex components on the aircraft to service safely.

Project record Build to print
{{ r.label }} {{ r.value }}
Build-to-print fabrication Marine Corps specifications Assembled on site, not shipped unverified MCAS Cherry Point, North Carolina
01 The challenge

The Most Complex Component on the Aircraft

The V-22's tiltrotor nacelle system demands extreme precision and uncompromising safety protocols, housing critical engine and gearbox systems. Existing maintenance processes needed a safer, more repeatable solution to reduce operational risk during nacelle removal and installation — with strict adherence to military engineering specifications.

A nacelle that isn't fully supported during removal risks damage to the component and the airframe around it — which is why the fixture, not the technique, had to carry the precision.

The JE-fabricated V-22 Osprey nacelle maintenance fixture
Fabricated to Marine Corps drawings, then validated against the aircraft it serves.
